SUN-18-25K-G06P3-EU-AM2
String inverter · Three-phase · 18 – 25 kW
18 – 25 kWThree-phaseIP65
Price on request
18 – 25 kWRated power
Three-phasePhase
2MPPT trackers
98.2 %Max. efficiency
Technical data
| SUN-18K-G06P3-EU-AM2 | SUN-20K-G06P3-EU-AM2 | SUN-22K-G06P3-EU-AM2 | SUN-23K-G06P3-EU-AM2 | SUN-25K-G06P3-EU-AM2 | |
|---|---|---|---|---|---|
| PV input | |||||
| Max. PV input power (W) | 27000 | 30000 | 33000 | 34500 | 37500 |
| Max. PV input voltage (V) | 1100 | ||||
| Rated PV input voltage (V) | 600 | ||||
| MPPT voltage range (V) | 200 – 1000 | ||||
| Start-up voltage (V) | 150 | ||||
| Max. input current per MPPT (A) | 32 | 32 | 36 | 36 | 36 |
| Max. short-circuit current per MPPT (A) | 48 | 48 | 54 | 54 | 54 |
| Number of MPPT trackers | 2 | ||||
| PV strings per MPPT | 2 | ||||
| AC output | |||||
| Rated output power (W) | 18000 | 20000 | 22000 | 23000 | 25000 |
| Max. apparent power (VA) | 19800 | 22000 | 24200 | 25300 | 27500 |
| Rated AC voltage (V) | 400 | ||||
| Rated AC output current (A) | 26.1 | 29 | 31.9 | 33.4 | 36.3 |
| Phase | Three-phase | ||||
| Rated AC frequency (Hz) | 50/60 | ||||
| Max. AC output current (A) | 28.7 | 31.9 | 35.1 | 36.7 | 39.9 |
| Total harmonic distortion (THDi) (%) | <3 | ||||
| Power factor | 0.8 leading to 0.8 lagging | ||||
| Grid connection type | 3L/N/PE | ||||
| Rated AC voltage options (V) | 220/380; 230/400 | ||||
| AC voltage range (relative to rated voltage) | 0.85 Un-1.1 Un | ||||
| AC grid frequency range (50 Hz / 60 Hz) (Hz) | 45-55 / 55-65 | ||||
| DC injection current | <0.5% In | ||||
| Efficiency | |||||
| Max. efficiency (%) | 98.2 | ||||
| European efficiency (%) | 97.7 | ||||
| MPPT efficiency (%) | >99 | ||||
| Protection | |||||
| Protection functions | DC reverse polarity protection; AC output overcurrent protection; AC output overvoltage protection; AC output short-circuit protection; thermal protection; insulation impedance detection; DC component monitoring; arc fault circuit interrupter (AFCI) (optional); anti-islanding protection; residual current detection; DC switch | ||||
| Surge protection level | Type II (DC), Type II (AC) | ||||
| Anti-PID function | Optional | ||||
| General data | |||||
| Dimensions (W x H x D) (mm) | 283 × 525 × 224 | ||||
| Weight (kg) | 12.7 | 12.7 | 16 | 16 | 16 |
| Ingress protection (IP rating) | IP65 | ||||
| Operating temperature range (°C) | −25 – 60 | ||||
| Relative humidity (%) | 0 – 100 | ||||
| Max. operating altitude (m) | 4000 | ||||
| Cooling | Intelligent air cooling | ||||
| Topology | Non-isolated | ||||
| Warranty (years) | 5 | ||||
| Overvoltage category | OVC II (DC), OVC III (AC) | ||||
| Communication | |||||
| Display | LCD1602 | ||||
| Communication interfaces | RS485; RS232; Wi-Fi; LAN | ||||
| Monitoring | String intelligent monitoring (optional) | ||||
| Certifications | |||||
| Certifications and standards | IEC/EN 61000-6-1/2/3/4; IEC/EN 62109-1; IEC/EN 62109-2 | ||||
| Grid codes | IEC 61727; IEC 62116; CEI 0-21; EN 50549; NRS 097; RD 140; UNE 217002; OVE-Richtlinie R25; G99; VDE-AR-N 4105 | ||||
Values from the manufacturer's datasheet, pending final confirmation. The datasheet supplied with the product prevails.
