220 WPeak power
17.55 %Module efficiency
2.6 kgWeight
IP67Protection class
Technical data
| LS-PV F220 | |
|---|---|
| Solar panel | |
| Peak power (Pmax) (W) | 220 |
| Open-circuit voltage (Voc) (V) | 23.6 |
| Short-circuit current (Isc) (A) | 11.9 |
| Voltage at max. power (Vmp) (V) | 19.6 |
| Current at max. power (Imp) (A) | 11.23 |
| Module efficiency (%) | 17.55 |
| Solar cell type | Monocrystalline silicon |
| Cell number / layout | MONO182 (6 x 12) |
| Cell type / dimensions | 182 x 83 mono |
| Cell string connection | Parallel |
| Number of diodes | 2 |
| Maximum series fuse rating (A) | 20 |
| Max. system voltage (V) | 600 |
| Power tolerance (%) | ±3 |
| Temperature coefficient of Pmax (Pmpp) (%/°C) | -0.38001 |
| Temperature coefficient of Voc (%/°C) | -0.29506 |
| Temperature coefficient of Isc (%/°C) | +0.08558 |
| Max. bending angle (°) | 120 |
| Cable length (m) | 3 |
| Output cable cross-section (mm²) | 2.5 |
| Test conditions (STC) | 1000 W/m², 25 °C, AM 1.5 |
| General data | |
| Dimensions (W x H x D) (mm) | 1150 × 1090 × 2 |
| Weight (kg) | 2.6 |
| 2-in-1 carton dimensions (inner) (mm) | 1170 × 1120 × 30 |
| Quantity per 20GP container (pcs) | 1300 |
| Ingress protection (IP rating) | IP67 |
| Junction box protection degree | IP67 or higher |
| Operating temperature range (°C) | −40 – 85 |
| Warranty (years) | 10 |
| Certifications | |
| Certifications and standards | CE |
Values from the manufacturer's datasheet, pending final confirmation. The datasheet supplied with the product prevails.
